Current Amplifier

Current Amplifier

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
1
Description

Features



Features



 Input capacitance 10nF at maximum.

● Output noise less than 1 mVrms .

● Compact design

● Amplify weak current in the cases of photoelectric conversion, STM, ion detection and etc.

● Input capacitance 10nF at maximum.

● Output noise less than 1 mVrms .

● Compact design

● Amplify weak current in the cases of photoelectric conversion, STM, ion detection and etc.

Caculation for bandwith



Caculation for bandwith



Application



To convert the week current signal (typically pA to nA). into a measurable voltage after being amplified by current amplifier. Such as:

● Scanning tunnel microscope

● Photodetector amplifier

● Optical spectrum

● Ionization detector

● Piezoelectric detectors

Application



To convert the week current signal (typically pA to nA). into a measurable voltage after being amplified by current amplifier. Such as:

● Scanning tunnel microscope

● Photodetector amplifier

● Optical spectrum

● Ionization detector

● Piezoelectric detectors

Specifications



  Specifications


Gain Bandwidth Rise time Noise(C=100p) Model
109V/A 1 kHz 300 μs 1 mVrms IVC100-1G-1K
4 kHz 82 μs 1.42 mVrms IVC100-1G-4K
108V/A 40 kHz 8.3 μs 5 mVrms IVC100-100M-40K



Power supply


Model PW1505H PW1502D
Type Swithing power supply Linear power supply
Input voltage 90 V~240 V     110 V or 220 V ± 10%
Output voltage ±15 V ± 15 V
Output current 500 mA 200 mA
Size/weight 11 x 6 x 3 CM / 0.2 Kg



We could not find any corresponding parameters, please add them to the properties table
Previous
Next
1/1
Number of views:
1000

Current Amplifier

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
1
Description

Features



Features



 Input capacitance 10nF at maximum.

● Output noise less than 1 mVrms .

● Compact design

● Amplify weak current in the cases of photoelectric conversion, STM, ion detection and etc.

● Input capacitance 10nF at maximum.

● Output noise less than 1 mVrms .

● Compact design

● Amplify weak current in the cases of photoelectric conversion, STM, ion detection and etc.

Caculation for bandwith



Caculation for bandwith



Application



To convert the week current signal (typically pA to nA). into a measurable voltage after being amplified by current amplifier. Such as:

● Scanning tunnel microscope

● Photodetector amplifier

● Optical spectrum

● Ionization detector

● Piezoelectric detectors

Application



To convert the week current signal (typically pA to nA). into a measurable voltage after being amplified by current amplifier. Such as:

● Scanning tunnel microscope

● Photodetector amplifier

● Optical spectrum

● Ionization detector

● Piezoelectric detectors

Specifications



  Specifications


Gain Bandwidth Rise time Noise(C=100p) Model
109V/A 1 kHz 300 μs 1 mVrms IVC100-1G-1K
4 kHz 82 μs 1.42 mVrms IVC100-1G-4K
108V/A 40 kHz 8.3 μs 5 mVrms IVC100-100M-40K



Power supply


Model PW1505H PW1502D
Type Swithing power supply Linear power supply
Input voltage 90 V~240 V     110 V or 220 V ± 10%
Output voltage ±15 V ± 15 V
Output current 500 mA 200 mA
Size/weight 11 x 6 x 3 CM / 0.2 Kg



We could not find any corresponding parameters, please add them to the properties table
